MV MX50 Heater Parts

Exploded Parts Diagram

      1. Water Jacket - Part No: M5Z-001
      2. Water Jacket Seals - Part No: M5Z-002
      3. Water Jacket Gasket - Part No: M5Z-003
      4. Exhaust Housing - Part No: M5Z-004
      5. Burner Assembly Gasket - Part No: M5Z-005
      6. Burner Assembly - Part No: M5C-006
      7. Water Pump - Part No: M5C-007(12V)/M5A-007(24V)
      8. Water Pump Clamp - Part No: M5Z-008
      9. Water Pump Hose - Part No: M5Z-009
      10. Water Pump Hose Clamp - Part No: M5Z-010
      11. Air Motor Gasket - Part No: M5Z-011
      12. Air Motor Assembly - Part No: M5C-012(12V)/M5A-012(24V)
      13. Combustion Air Fan - Part No: M5Z-014
      14. O-Ring - Part No: M5Z-015
      15. Air Motor Cover - Part No: M5Z-016
      16. Air Motor Housing Grommet - Part No: M5Z-017
      17. Fuel Inlet Grommet - Part No: M5Z-018
      18. Glow Pin - Part No: M5C-018(12V)/M5A-018(24V)
      19. Water Temperature Sensor - Part No: M5Z-019
      20. Holder - Part No: M5Z-022
      21. ECU - Part No: M5C-024(12V)/M5A-024(24V)
      22. ECU Base Gasket - Part No: M5Z-025
      23. ECU Cover Gasket - Part No: M5Z-026
      24. ECU Cover - Part No: M5Z-027
