MV Airo 2 Boost Parts

Exploded Heater Parts Diagram

      1. Heat Exchanger Assembly - Part No: A2BZ-001
      3. Burner Assembly - Part No: A2BZ-003
      5. Air Motor - Part No: A2BC-005(12V)A2BA-005(24V)
      7. Overheat Sensor - Part No: A2B4Z-011
      9. Glow Pin - Part No: A2B4C-014(12V)/A2B4A-014(24V)
      11. Top Case - Part No: A2BZ-020
      13. Outlet Cover - Part No: A2BZ-022
      15. Mounting Gasket - Part No: A2B4Z-030
      2. Burner Gasket - Part No: A2BZ-002
      4. Air Motor Gasket - Part No: A2BZ-004
      6. E.C.U. - Part No: A2BC-010(12V)/A2BA-010(24V)
      8. Retaining Spring Clip - Part No: A2BZ-012
      10. Glow Pin Screen - Part No: A2BZ-015
      12. Bottom Case - Part No: A2BZ-021
      14. Inlet Grill - Part No: A2BZ-023
